2















I managed to align my hypotenuse text with the hypotenuse side of my triangle, but I feel like it was done inefficiently using a lot of ~~~~~~ in this line node[above] $sqrt1+x^2$~~~~~~~ (B) --.



Is there a better way to get the same alignment that I have now without the excessive use of ~?



enter image description here



documentclass[hidelinks,14pt, letterpaper]extarticle
usepackageamsmath, amssymb, tikz

newcommandpythagwidth3cm
newcommandpythagheight2cm

begindocument
beginfigure[h]
centering

begintikzpicture[scale=1.25]
coordinate [label=left:$A$] (A) at (-1.5cm,-1.cm);
coordinate [label=above:$B$] (B) at (1.5cm,1.0cm);
coordinate [label=below right:$C$] (C) at (1.5cm,-1.0cm);
draw
(A) --
node[above] $sqrt1+x^2$~~~~~~~ (B) --
node[right] ? (C) --
node[below] ?
(A);
draw
(1.25cm,-1.0cm) rectangle (1.5cm,-0.75cm);

endtikzpicture
captionCaption
labelfig:my_label
endfigure
enddocument









share|improve this question


























    2















    I managed to align my hypotenuse text with the hypotenuse side of my triangle, but I feel like it was done inefficiently using a lot of ~~~~~~ in this line node[above] $sqrt1+x^2$~~~~~~~ (B) --.



    Is there a better way to get the same alignment that I have now without the excessive use of ~?



    enter image description here



    documentclass[hidelinks,14pt, letterpaper]extarticle
    usepackageamsmath, amssymb, tikz

    newcommandpythagwidth3cm
    newcommandpythagheight2cm

    begindocument
    beginfigure[h]
    centering

    begintikzpicture[scale=1.25]
    coordinate [label=left:$A$] (A) at (-1.5cm,-1.cm);
    coordinate [label=above:$B$] (B) at (1.5cm,1.0cm);
    coordinate [label=below right:$C$] (C) at (1.5cm,-1.0cm);
    draw
    (A) --
    node[above] $sqrt1+x^2$~~~~~~~ (B) --
    node[right] ? (C) --
    node[below] ?
    (A);
    draw
    (1.25cm,-1.0cm) rectangle (1.5cm,-0.75cm);

    endtikzpicture
    captionCaption
    labelfig:my_label
    endfigure
    enddocument









    share|improve this question
























      2












      2








      2


      1






      I managed to align my hypotenuse text with the hypotenuse side of my triangle, but I feel like it was done inefficiently using a lot of ~~~~~~ in this line node[above] $sqrt1+x^2$~~~~~~~ (B) --.



      Is there a better way to get the same alignment that I have now without the excessive use of ~?



      enter image description here



      documentclass[hidelinks,14pt, letterpaper]extarticle
      usepackageamsmath, amssymb, tikz

      newcommandpythagwidth3cm
      newcommandpythagheight2cm

      begindocument
      beginfigure[h]
      centering

      begintikzpicture[scale=1.25]
      coordinate [label=left:$A$] (A) at (-1.5cm,-1.cm);
      coordinate [label=above:$B$] (B) at (1.5cm,1.0cm);
      coordinate [label=below right:$C$] (C) at (1.5cm,-1.0cm);
      draw
      (A) --
      node[above] $sqrt1+x^2$~~~~~~~ (B) --
      node[right] ? (C) --
      node[below] ?
      (A);
      draw
      (1.25cm,-1.0cm) rectangle (1.5cm,-0.75cm);

      endtikzpicture
      captionCaption
      labelfig:my_label
      endfigure
      enddocument









      share|improve this question














      I managed to align my hypotenuse text with the hypotenuse side of my triangle, but I feel like it was done inefficiently using a lot of ~~~~~~ in this line node[above] $sqrt1+x^2$~~~~~~~ (B) --.



      Is there a better way to get the same alignment that I have now without the excessive use of ~?



      enter image description here



      documentclass[hidelinks,14pt, letterpaper]extarticle
      usepackageamsmath, amssymb, tikz

      newcommandpythagwidth3cm
      newcommandpythagheight2cm

      begindocument
      beginfigure[h]
      centering

      begintikzpicture[scale=1.25]
      coordinate [label=left:$A$] (A) at (-1.5cm,-1.cm);
      coordinate [label=above:$B$] (B) at (1.5cm,1.0cm);
      coordinate [label=below right:$C$] (C) at (1.5cm,-1.0cm);
      draw
      (A) --
      node[above] $sqrt1+x^2$~~~~~~~ (B) --
      node[right] ? (C) --
      node[below] ?
      (A);
      draw
      (1.25cm,-1.0cm) rectangle (1.5cm,-0.75cm);

      endtikzpicture
      captionCaption
      labelfig:my_label
      endfigure
      enddocument






      tikz-pgf






      share|improve this question













      share|improve this question











      share|improve this question




      share|improve this question










      asked 3 hours ago









      Evan KimEvan Kim

      1503




      1503




















          2 Answers
          2






          active

          oldest

          votes


















          5














          Something like this? I use node[midway,above left=0pt,inner sep=0.5pt] $sqrt1+x^2$, where inner sep=0.5pt controls the distance.



          documentclass[hidelinks,14pt, letterpaper]extarticle
          usepackageamsmath, amssymb, tikz

          newcommandpythagwidth3cm
          newcommandpythagheight2cm

          begindocument
          beginfigure[h]
          centering

          begintikzpicture[scale=1.25]
          coordinate [label=left:$A$] (A) at (-1.5cm,-1.cm);
          coordinate [label=above:$B$] (B) at (1.5cm,1.0cm);
          coordinate [label=below right:$C$] (C) at (1.5cm,-1.0cm);
          draw
          (A) --
          node[midway,above left=0pt,inner sep=0.5pt] $sqrt1+x^2$ (B) --
          node[right] ? (C) --
          node[below] ?
          (A);
          draw
          (1.25cm,-1.0cm) rectangle (1.5cm,-0.75cm);

          endtikzpicture
          captionCaption
          labelfig:my_label
          endfigure
          enddocument


          enter image description here



          ADDENDUM: Just for fun: an even simpler and shorter code with TikZ...



          documentclass[tikz,border=3.14mm]standalone
          begindocument
          begintikzpicture[scale=1.25]
          draw (-1.5,-1) coordinate [label=left:$A$] (A) --
          node[midway,above,sloped] $sqrt1+x^2$
          (1.5,1) coordinate [label=above:$B$] (B) --
          node[right] ?
          (1.5,-1)coordinate [label=below right:$C$] (C) --
          node[below] ? cycle;
          draw ([xshift=-0.25cm]C) |- ([yshift=0.25cm]C);
          endtikzpicture
          enddocument


          enter image description here






          share|improve this answer

























          • yes that is it thanks! It seems like simply having node [midway,above left=0pt] $sqrt1+x^2$ (B) -- does the trick too without using inner_sept

            – Evan Kim
            3 hours ago



















          1














          Just for fun: with pstricks, a very short code to have this figure:



           documentclassarticle
          usepackagepst-eucl%,
          usepackageauto-pst-pdf

          begindocument

          beginpostscript
          pssetunit=2, linejoin=1, PointSymbol=none,
          pstTriangle(-1.5,-1)A(1.5,1)B(1.5,-1)C
          ncline[linestyle=none]ABnaput*[nrot=:U]$ sqrt1 + x^2$
          pssetPointName=none
          pstMiddleABACIuput[d](I)?
          pstMiddleABBCJuput[r](J)?
          endpostscript

          enddocument


          enter image description here






          share|improve this answer
